We still have other models of roll forming machine, and can also support customization, any questions, please feel free to send us inquiry.
|
1. Raw material |
|
|
material spec |
sheet, galvanized steel sheet, aluminum sheet |
|
Input width |
300mm |
|
thickness of coil sheet |
0.5-0.7mm |
|
2. Machine details |
|
|
roller material |
high grade NO. 45 forged steel with 0.05mm hard chrome plating |
|
shaft material |
high grade NO. 45 carbon wrought steel |
|
cutting blade |
Cr12 mould steel with quenched treatment |
|
diameter of shaft |
80mm or as your requirement |
|
main frame |
300 H steel |
|
forming steps |
18 rows |
|
productivity |
20-25 m/min |
|
hydraulic station power |
22KW |
|
hydraulic pressure |
10-12MPa |
|
controlling system |
famous PLC computer control |
|
material of cutting table |
Cr 12 mould steel with quenched treatment |
|
appearance size |
8500mm*1000mm*1500mm |
|
hydraulic oil |
40# hydraulic oil |
|
Electric tension |
380V 50 Hz 3 Phase or as your requirements |
Warranty
Two years, and we will provide technical support for wholelife of the equipment.
If some parts of machine broken within 2 year, we will give customer the spare parts for free. (include chain, bearing, roller,oil pipe, counting wheel) If more than 2 year, maybe some spare parts need to be charged. If machine can not work well, we can teach them online until the machine is perfect. If you need, we can go to your place to assist you. But you need to provide the cost of the engineer.
Botou Zhongchao International Trade Co., Ltd. was established in 2018. Our company is a comprehensive enterprise integrating production, sales and services and tranding in all kinds of machinery. We are mainly devoted to the development and manufacturing of metal plate cold bending roll forming equipment.
We have high quality professional teams, skillful talents,strong technical force,strong and independent research and development capabilities, advanced production equipment and a perfect after-sales service system.
We have great confidence in the quality and precision of our products. Our customers feedback said that it is a great machine, no noise, clean, very advanced technology. And it also has the features of light structure and reasonable design.
We manufacture wide range products of metal sheet cold roll forming machine as follows: color steel roll forming machine, glazed tile roll forming machine, C/Z/U purlin machine for light steel structure building, floor deck machine, sandwich panel production line, fast guardrail forming machine, ridge cap forming machine and other automatic cold bending roll forming equipment. Our export team will listen to your request; the designed team will show you the best proposal according to your request, and we also have experts skilled workers offer precision work. Satisfactory solutions were provided to customers and established a long-term strategic partnership.
Packing Method
Main machine is packaged with plastic film
Transportation
All machines need one 40 feet container to hold
Payment Term
30% deposit by T/T in advance and 70% balance after inspection confirmation before shipment.
Delivery Time
Within 35 days after receiving deposit.
| Contact Person : | Robert Freeman |
|---|
